Description

Descriptions:

  • Contains a controller inside, connecting solar panels and batteries, to build a complete solar system.
  • There are different connectors on the cube, which users can connect to their loadings directly.
  • There are inbuilt protection functions.
  • Largely simplify a solar system, both installation and usage..



Model No. SW-SHK10 SW-SHK20
Controller 12V/10A, PWM, LED indicator 12V/20A, PWM,LED indicator
Output Voltage DC12, DC5V
DC Outlet Socket DC12V Socket*8, 18W Quick Charge USB*1, 5V/2.1A USB*1
Equipped Accessories 5W LED bulb with 5m cable with switch, 6 sets
3 in 1 USB cable, 1pc
Protections Surge, Reverse polarity, Overload, Short circuit ,etc.
Operating Temperature Discharge: -20℃ ~50℃，Charge: 0℃~50℃
Power Box Size(L*W*H) 200*145*40mm
Allowed Solar Panel Max 160W Max 320W
Allowed Battery Lead-acid or LFP
Suitable Battery Cable 4mm2/1.5m 6mm2/1.5m
